Precision Solar Mounts: Heavy-Duty, Fast-Installation Steel Supports

Core Design Specifications

Material: Constructed from high-strength, hot-dip galvanized steel (Grade S355JR). Features a G90 zinc coating with a minimum density of 610g/㎡ for maximum durability.
Tilt Range: Offers a flexible tilt adjustment from 10° to 60°, designed for compatibility with both fixed-angle setups and automated solar tracking systems.
Structural Performance: Engineered to withstand extreme environmental loads, including wind speeds up to 60m/s (per AS/NZS 1170.2) and snow loads of 5.5kN/㎡ (IBC 2021 compliant).
Corrosion Protection: Demonstrates exceptional longevity, passing rigorous 2000-hour salt spray testing in accordance with ISO 9227.

Key System Advantages

Fast Assembly: Incorporates a modular, bolt-together design with pre-drilled components, reducing installation time by approximately 50% compared to traditional welded frameworks.
Slope Compatibility: Adjustable foundation system accommodates uneven terrain and slopes up to 30 degrees without requiring extensive site leveling.
Sustainable Manufacturing: Utilizes 100% recyclable steel components and is manufactured with zero on-site waste generation, supporting eco-friendly project deployment.

Integrated Features

• Ready for IoT connectivity with optional embedded tilt sensors.

• Includes pre-assembled cable routing brackets for neat and secure wire management.

Compliance & Warranty

• Certified to UL 2703 and IEC 62817 standards for safety and performance.

• Manufacturing process is certified under ISO 14064-1 for low carbon footprint.

• Backed by a 25-year product warranty, validated for use in demanding coastal and desert climates.
