Mine Roadway Support Steel Fabrication Engineered For Underground Stability

20 T
MOQ
USD1000/T-USD1200/T
Price
Mine Roadway Support Steel Fabrication Engineered For Underground Stability
Features Gallery Product Description Request A Quote
Features
Specifications
Weather Resistance: Yes
Cost: Affordable
Customization Options: Available
Raw Steel Material: Q235B, Q355B, ASTM A36, ASTM572
Application: Steel Structural Building
Color: Optional
Production Capacity: 12500T Per Month
Standard: AISC, ASTM, EN, BS, DIN, GB, JIS
Fire Resistance: Yes
Design: Customized
Durability: High
Surface Treatment: Painting Or Hot-dip Galvanized
Columns And Beam: H Section Column&Beam
Size: Customized
Customizable: Yes
Highlight:

Mine Roadway Support Steel Fabrication

,

Engineered Steel Fabrication

,

Underground Steel Fabrication

Basic Infomation
Brand Name: SUNWAY
Payment & Shipping Terms
Packaging Details: Steel Pallet
Delivery Time: 30-40 days
Payment Terms: L/C,T/T
Supply Ability: 100000T/Year
Product Description

Mine Roadway Support System: Engineered for Underground Stability

Mine Roadway Support Steel Fabrication Engineered For Underground Stability 0

Safeguarding mining operations with robust steel arches designed for high-stress tunnels and dynamic geological conditions.

Core Specifications

  • Material‌: High-yield steel (Q460C/EN S690QL) with yield strength ≥690 MPa
  • Profile‌: Semi-circular or trapezoidal arches (4-8m span, 0.8-2.2m height)
  • Load Capacity‌: Static 0.5 MPa / Dynamic 0.3 MPa (ISO 14688-2 compliant)

Critical Design Features

  • Active Ground Control‌: Pre-tensioned cross-struts counteract rockbursts and convergence
  • Modular Assembly‌: Bolt-connected segments enable rapid deployment in confined spaces
  • Corrosion Defense‌: Hot-dip galvanizing (≥86μm) + coal tar epoxy coating for acidic environments
  • Deformation Monitoring‌: RFID tags embedded for real-time stress monitoring via 5G mesh networks

Geotechnical Adaptability

  • Coal seams with gas outburst risks (ATEX Zone 1 certified)
  • Soft rock tunnels with >15% creep deformation
  • Deep mines (>1000m) under high geothermal stress

Compliance & Certification

  • MSHA 30 CFR Part 75 roof control standards
  • ISO 14689-1 geotechnical investigation alignment
  • EN 1090-2 execution class EXC4 for critical structures

Where geology challenges productivity, our steel arches deliver resilience.



Mine Roadway Support Steel Fabrication Engineered For Underground Stability 1

Product name    Mine Roadway Support System
Material     ASTM; EN; GB;
Surface     Painted; HDG



Mine Roadway Support Steel Fabrication Engineered For Underground Stability 2



Mine Roadway Support Steel Fabrication Engineered For Underground Stability 3

OEM service available.

A dedicated team of fast response;

EN1090 & AISC & CWB & JIS Certificated Quality;

Full production line for customized products;

Close to Sea port, Convenient for visit and delivery;

150000M2 Manufacturing Area capable to take large volume



Mine Roadway Support Steel Fabrication Engineered For Underground Stability 4

Mine Roadway Support Steel Fabrication Engineered For Underground Stability 5

Mine Roadway Support Steel Fabrication Engineered For Underground Stability 6
